PERFORMANCE

Processor
AMD Ryzen™ 7 170 (8C / 16T, 3.2 / 4.75GHz, 4MB L2 / 16MB L3)
Graphics
NVIDIA GeForce RTX™ 5050 8GB GDDR7, Boost Clock 2662MHz, TGP 65W, 440 AI TOPS
Chipset
AMD SoC Platform
Memory
1x 16GB SODIMM DDR5-4800
Memory Slots
Two DDR5 SODIMM slots, dual-channel capable
Max Memory
Up to 16GB DDR5-4800 offering
Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot
Two M.2 slots
• One M.2 2242 PCIe® 4.0 x4 slot
• One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB
Optical
None
Card Reader
No Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, optimized with Nahimic Audio
Microphone
2x, Array
Camera
HD 720p with E-shutter
Battery
60Wh
Power Adapter
135W Slim Tip (3-pin)

DESIGN

Display
15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, FreeSync™
Touchscreen
None
Screen-to-Body Ratio
88.07% AAR (active area ratio)
Color Calibration
No Color Calibration
Pen
Pen Not Supported
Keyboard
White Backlit, English
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 69 x 104 mm (2.72 x 4.09 inches)
Dimensions (WxDxH)

361.26 x 255.6 x 22.9-24.8 mm (14.22 x 10.06 x 0.90-0.98 inches)
Weight

Starting at 2.3 kg (5.07 lbs)
Case Color
Eclipse Black
Case Material
PC-ABS (Top), PC-ABS (Bottom)
Surface Treatment
Painting

SOFTWARE

Operating System
Windows® 11 Home, English
Bundled Software
Office Trial

CONNECTIVITY

WLAN + Bluetooth
Wi-Fi® 6, 802.11ax 2x2 + BT5.2
WWAN
WWAN Not Supported
Ethernet
100/1000M (RJ-45)
Standard Ports

2x USB-A (USB 5Gbps)
1x USB-C® (USB 5Gbps), with USB PD 65-100W
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Slim tip Power connector

Docking
Various docking solutions supported via USB-C®.
For more compatible docking solutions, please visit Docking for LOQ™ Essential 15ARP11
SECURITY & PRIVACY

Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
No Fingerprint Reader
Other Security
E-shutter

SERVICE

Included Upgrade
None

ACCESSORIES

Bundled Accessories
None

CERTIFICATIONS

Green Certifications

ErP Lot 6/26
RoHS compliant

MODEL INFORMATION

Model
83VA001PUS
Machine Type
83VA
Region
NA
Country/Region
USA
TopSeller
No
EAN / UPC / JAN
199275048142
