PERFORMANCE

Processor
Intel® Core™ i5-12450HX, 8C (4P + 4E) / 12T, P-core up to 4.4GHz, E-core up to 3.1GHz, 12MB
AI PC Category

AI-Powered Gaming PC
Graphics
NVIDIA® GeForce RTX™ 2050 4GB GDDR6, Boost Clock 1575MHz, TGP 65W
Chipset
Intel® HM670 Chipset
Memory
1x 12GB SO-DIMM DDR5-4800
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory

Up to 32GB DDR5-4800
Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Max Storage Support

Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB each
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Card Reader
None
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera
HD 720p with E-shutter
Microphone
2x, Array
Battery
60Wh
Power Adapter
135W Slim Tip (3-pin)
Special Features
AI Chip: LA1
DESIGN
Display

15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC®
Touchscreen
None
Color Calibration
None
Keyboard
White Backlit, English (US)
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Case Color
Luna Grey
Surface Treatment
Painting
Case Material
PC-ABS (Top), PC-ABS (Bottom)
Pen
Pen Not Supported
Dimensions (WxDxH)

359.86 x 258.7 x 21.9-23.9 mm (14.17 x 10.19 x 0.86-0.94 inches)
Weight

Starting at 2.38 kg (5.25 lbs)
SOFTWARE
Operating System
Windows® 11 Home, English
Bundled Software
Office Trial
CONNECTIVITY
WLAN + Bluetooth

Wi-Fi® 6, 802.11ax 2x2 + BT5.2
WWAN
Non-WWAN
Ethernet
Integrated 100/1000M
Standard Ports

3x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with Lenovo® PD 140W and DisplayPort™ 1.4
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Power connector

Docking
Various docking solutions supported via USB-C®.
For more compatible docking solutions, please visit Docking for LOQ™ 15IAX9
SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
None
Other Security
E-shutter
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications

ErP Lot 3
RoHS compliant

Other Certifications
TÜV Rheinland® Low Blue Light (Software Solution)
Mil-Spec Test
MIL-STD-810H military test passed
MODEL INFORMATION
Model
83GS001BUS
Country/Region
USA
TopSeller
No
EAN / UPC / JAN
197531780485
