Legion 5 15IRX10 83LY0000US

PERFORMANCE

Processor
Intel® Core™ i7-14700HX, 20C (8P + 12E) / 28T, P-core 2.1 /
5.5GHz, E-core 1.5 / 3.9GHz, 33MB
AI PC Category[1]
AI-Powered Gaming PC
NPU
None
Graphics
NVIDIA® GeForce RTX™ 5060 8GB GDDR7, Boost Clock
2497MHz, TGP 115W, 572 AI TOPS
Chipset
Intel® HM770 Chipset
Memory
1x 16GB SO-DIMM DDR5-5600
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory[2]
Up to 32GB DDR5-5600 offering
Storage
1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Max Storage Support[3]
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB each
Optical
None
Card Reader
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, audio by HARMAN, optimized with
Nahimic Audio
Microphone
2x, Array
Camera
5.0MP with E-shutter
Battery
80Wh
Power Adapter
245W Slim Tip (3-pin)
Special Features
AI Chip: LA1

DESIGN

Display
15.1" WQXGA (2560x1600) OLED 1000nits (peak) / 500nits
(typical) glossy, 100% DCI-P3, 165Hz, Dolby Vision®,
DisplayHDR™ True Black 600
Touchscreen
None
Screen-to-Body Ratio
OLED models: 90% AAR (active area ratio)
Color Calibration
Factory Color Calibration
Pen
Pen Not Supported
Keyboard
24-Zone RGB Backlit, English
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports
Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (WxDxH)[4]
344.9 x 255.35 x 19.95-21.54 mm (13.58 x 10.05 x 0.79-0.85
inches)
Weight[5]
Starting at 1.9 kg (4.19 lbs)
Case Color
Eclipse Black
Case Material
Aluminium (Top), PC-ABS + 15% Talc (Bottom)
Surface Treatment
Aluminium Stamping (Anodized with Sandblasting)

SOFTWARE

Operating System
Windows® 11 Home, English
Bundled Software
Office Trial + Lenovo® AI Now

CONNECTIVITY

WLAN + Bluetooth®[6]
Wi-Fi® 7, 802.11be 2x2 + BT5.4
WWAN
Non-WWAN
Ethernet
100/1000M (RJ-45)
Standard Ports[7]
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)•
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On•
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD
65-100W and DisplayPort™ 2.1
•
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with
DisplayPort™ 1.4
•
1x HDMI® 2.1, up to 8K/60Hz•
1x Headphone / microphone combo jack (3.5mm)•
1x Ethernet (RJ-45)•
1x Power connector•
Docking
Various docking solutions supported via USB-C®.
For more compatible docking solutions, please visit Docking
for Legion 5 15IRX10

SECURITY & PRIVACY

Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
None
Other Security
E-shutter
