INALAMBRICO

Estándares Wi-Fi 6
• IEEE 802.11ax/ac/n/a 5 GHz
• IEEE 802.11ax/n/b/g 2.4 GHz
Velocidad WiFi AX3000
• 5 GHz: 2402 Mbps (802.11ax, HE160)
• 2.4 GHz: 574 Mbps (802.11ax)

Rango WiFi

3 Bedroom Houses• 4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas

• Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range

• High-Power FEM
Improves transmission power to strengthen signal coverage

Capacidad WiFi

High• Dual-Band
Allocate devices to different bands for optimal performance

• OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients

• Airtime Fairness
Improves network efficiency by limiting excessive occupation

• DFS
Access an extra band to reduce congestion

• 4 Streams
Connect your devices to more bandwidth


Modos de trabajo

• Router Mode
• Access Point Mode

HARDWARE

Puertos ethernet

• 1× 2.5 Gigabit WAN/LAN Port
• 1× Gigabit WAN/LAN Port
• 3× Gigabit LAN Ports

Soporte USB

1× USB 3.0 Port

Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32

Supported Functions:

Apple Time Machine
FTP Server
Media Server
Samba Server

Botones

Wi-Fi/WPS Button
Power On/Off Button
Reset Button

Energía

• 12 V/ 2 A (US Version)
• 12 V/ 1.5 A (EU Version)

SEGURIDAD

Cifrado WiFi

• WPA3*
• WPA2
• WPA
• WPA/WPA2-Enterprise (802.1x)

Seguridad de la red

SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway

HomeShield SecurityReal-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner

Red de invitados

• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network
Servidor VPN • OpenVPN
• PPTP
• L2TP
Cliente VPN • OpenVPN
• PPTP
• L2TP
SOFTWARE
Protocolos • IPv4
• IPv6
Kits de servicio HomeShield

Controles parentales

HomeShield Parental Controls

• Custom Profiles
• Professional Content Filter Library
• Family Time
• Bedtime
• Off Time
• Time Rewards
• Family Online Time Ranking
• Pause the Internet
• Weekly and Monthly Reports

Tipos de WAN

• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP

Calidad de servicio

QoS by Device

Cloud Service

• Auto Firmware Upgrade
• OTA Firmware Upgrade
• TP-Link ID
• DDNS

NAT Forwarding

• Port Forwarding
• Port Triggering
• DMZ
• UPnP

IPTV

• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN

DHCP

• Address Reservation
• DHCP Client List
• Server

DDNS

• TP-Link
• NO-IP
• DynDNS

Gestión

• Tether App
• Webpage

Check Web Emulator>
OTRO
Requisitos del sistema Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)
Certificaciones FCC, CE, RoHS
Ambiente Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing

DATOS DE PRUEBA

Potencia de transmisión WiFi

• CE:
